45° Flange 3000 PSI (one-piece)


45° Flange 3000 PSI (one-piece)
CODE DN INCHES DIAM D L
F45L0808I 12 1/2" 8 1/2" 63
F45L0810I 12 1/2" 8 5/8" 68
F45L0812I 12 1/2" 8 3/4" 68
F45L1008I 16 5/8" 10 1/2" 59
F45L1010I 16 5/8" 10 5/8 " 63
F45L1012I 16 5/8" 10 3/4" 63
F45L1208I 20 3/4" 12 1/2" 63
F45L1212I 20 3/4" 12 3/4" 67
F45L1216I 25 3/4" 12 1" 70
F45L1612I 25 1" 16 3/4" 83
F45L1616I 25 1" 16 1" 86
F45L1620I 25 1" 16 1.1/4" 90
F45L2016I 32 1.1/4" 16 1" 96
F45L2020I 32 1.1/4" 20 1.1/4" 100
F45L2024I 32 1.1/4" 20 1.1/2" 101
F45L2424I 40 1.1/2" 24 1.1/2" 112
F45L2432I 40 1.1/2" 24 2" 123
F45L3232I 50 2" 32 2" 148

* The figures and technical data set out in the tables are only intended as approximations.
