45° O-ring metric female swept elbow 24° cone - L type


45° O-ring metric female swept elbow 24° cone - L type
CODE DN INCHES DIAM D L
F45E0312L6 5 3/16" 3 M12x1.5 6
F45E0314L8 5 3/16" 3 M14x1.5 8
F45E0412L6 6 1/4" 4 M12x1.5 6
F45E0414L8 6 1/4" 4 M14x1.5 8
F45E0416L10 6 1/4" 4 M16x1.5 10
F45E0418L12 6 1/4" 4 M18x1.5 12
F45E0514L08 8 5/16" 5 M14x1.5 8
F45E0516L10 8 5/16" 5 M16x1.5 10
F45E0518L12 8 5/16" 5 M18x1.5 12
F45E0616L10 10 3/8" 6 M16x1.5 10
F45E0618L12 10 3/8" 6 M18x1.5 12
F45E0622L15 10 3/8" 6 M22x1.5 15
F45E0818L12 12 1/2" 8 M18x1.5 12
F45E0822L15 12 1/2" 8 M22x1.5 15
F45E0826L18 12 1/2" 8 M26x1.5 18
F45E1026L18 16 5/8" 10 M26x1.5 18
F45E1030L22 16 5/8" 10 M30x2 22
F45E1226L18 20 3/4" 12 M26x1.5 18
F45E1230L22 20 3/4" 12 M30x2 22
F45E1636L28 25 1" 16 M36x2 28
F45E2045L35 32 1.1/4" 20 M45x2 35
F45E2452L42 40 1.1/2" 24 M52x2 42

* The figures and technical data set out in the tables are only intended as approximations.
