90° JIC Female swept elbow 74° cone

90° JIC Female swept elbow 74° cone

Get your quote for 90° JIC Female swept elbow 74° cone

CODE DN INCHES DIAMETER D L
F90J0304 5 3/16" 3 7/16" 20
F90J0305 5 3/16" 3 1/2" 20
F90J0404 6 1/4" 4 7/16" 20
F90J0405 6 1/4" 4 1/2" 20
F90J0406 6 1/4" 4 9/16" 18
F90J0505 8 5/16" 5 1/2" 20
F90J0506 8 5/16" 5 9/16" 18
F90J0507 8 5/16" 5 5/8" 18
F90J0508 8 5/16" 5 3/4" 16
F90J0606 10 3/8" 6 9/16" 18
F90J0607 10 3/8" 6 5/8" 18
F90J0608 10 3/8" 6 3/4" 16
F90J0610 10 3/8" 6 7/8" 14
F90J0808 12 1/2" 8 3/4" 16
F90J0810 12 1/2" 8 7/8" 14
F90J0812 12 1/2" 8 1.1/16" 12
F90J1010 16 5/8" 10 7/8" 14
F90J1012 16 5/8" 10 1.1/16" 12
F90J1210 20 3/4" 12 7/8" 14
F90J1212 20 3/4" 12 1.1/16" 12
F90J1214 20 3/4" 12 1.3/16" 12
F90J1216 20 3/4" 12 1.5/16" 12
F90J1612 25 1" 16 1.1/16" 12
F90J1616 25 1" 16 1.5/16" 12
F90J1620 25 1" 16 1.5/8" 12
F90J2020 32 1.1/4" 20 1.5/8" 12
F90J2024 32 1.1/4" 20 1.7/8" 12
F90J2424 40 1.1/2" 24 1.7/8" 12

* The figures and technical data set out in the tables are only intended as approximations.
