90° O-ring Female swept elbow 24° cone - S type - INTERLOCK

CODE	DN	INCHES	DIAM	D	L
KF90E1230S20	20	3/4"	12	M30x2	20
KF90E1236S25	20	3/4"	12	M36x2	25
KF90E1636S25	25	1"	16	M36x2	25
KF90E1642S30	25	1"	16	M42x2	30
KF90E2042S30	32	1.1/4"	20	M42x2	30
KF90E2052S38	32	1.1/4"	20	M52x2	38
KF90E2452S38	40	1.1/2"	24	M52x2	38

* The figures and technical data set out in the tables are only intended as approximations.
