TUBOMATIC S220 ES / TUBS220ES

With a maximum opening of 500 mm with respect to the diameter to be crimped, S500 ES crimping machine is able to crimp industrial hoses up to 12'' with big flanges, thanks to the extra stroke of its dies holders.

Main Features

  • ES4 Siemens PLC control with 7'' color touch-screen display;
  • self lubricating moving components;
  • new silent pump;
  • "6 o'clock fixed position" of the die for greater stability of the hose during crimping;
  • particularly narrow crimping head to crimp hose ends with large flanges or 90° fittings;
  • back limit switch;
  • protractor for orientation fittings;
  • hydraulic power pack included;
  • mobile control board.

Product specifications could be modified without prior notice.

TUBOMATIC S220 ES


CRIMPING FORCE 450 TON (470 US TONS)
6 SPIRALS 2 PIECES 3''
INDUSTRIAL HOSE 10''
MAX Diam. 220 mm (8.661'')
MACHINE EXTRA STROKE Ø + 310 mm (+ 12.204'')
CRIMPING / HOUR 1200
CLOSING SPEED 16,5 mm/sec
CRIMPING SPEED 1,8 mm/sec
OPENING SPEED 23.8 mm/sec
DIE OPENING Ø + 58 mm (Ø + 2.631'')
STANDARD VOLTAGE 375V-420V 50HZ 3PH
MOTOR POWER 11 Kw (15 Hp) A=21,96
DIMENSIONS 1200x1175x2250 mm (47.28''x46.1''x88.65'')
WEIGHT WITHOUT OIL 3250 Kg (7165 Lbs)
OIL 300 lt
HYDRAULIC POWER PACK SEPARATED FROM THE MACHINE incl.
HYDRAULIC POWER PACK DIMENSIONS L x W x H 929x669x1314 mm (37.575''x26.339''x51.732'')
HYDRAULIC POWER PACK WEIGHT 315 Kg (694 Lbs)
DOUBLE ACTING CYLINDER incl.
BACK LIMIT SWITCH incl.
ELECTRONIC CONTROL WITH TOUCH SCREEN incl.
PROTRACTOR FOR ORIENTATION FITTINGS incl.
SETTABLE MAINTENANCE COUNTER FOR PERIODIC SERVICE OPTIONAL
PRESSURE CONTROL SYSTEM OPTIONAL
SPEED CONTROL SYSTEM OPTIONAL
QUALITY CHECK OPTIONAL
BARCODE OPTIONAL
WEBCAM OPTIONAL
CONNECTION FROM ES4 TO PC OPTIONAL
MARKING DIES OPTIONAL
SPECIAL DIES OPTIONAL
SPECIAL VOLTAGE OPTIONAL
DISPENSER + QUICK CHANGE OPTIONAL
MULTISTEP OPTIONAL
ELECTRIC PEDAL OPTIONAL
CRIMPING SPEED OPTIONAL
TOOL-HOLDER SUPPORT OPTIONAL
