Performance

• Gear ratio 22,1:1
• Pulling capacity 1st layer 10000 kg. [22000 lbs.]
• Speed line (based on 75 lt/min. [20 gpm] oil supply):
  1st layer 9,0 mt./min. [29,5 ft./min.]
  5th layer 16,8 mt./min. [55,1 ft./min.]

Features

• Two stage hardened steel planetary gears in oil bath
• Hydraulic multi disc negative brake system
• Over-centre valve
• Air Clutch for drum Freespooling
• Standard mounting angles
• Hydraulic orbital motor
• Drum length (distance between drum flanges):
  EPH 10000 standard drum 335 mm [13,2 in]
• Drum barrel dia.127 mm [5,0 in]
• Wire rope recommended dia.16 mm [5/8”]

Compliance

CE Machinery Directive  98/37/EEC

Accessories

• Galvanized Heavy-duty roller fairlead (rollers on bearings)
• Galvanized level winder (roller on bearings)

---
