Performance

• Gear ratio 5,3:1
• Pulling capacity 1st layer 6000 kg. [13300 lbs.]
• Speed line (based on 60 lt/min. [16 gpm] oil supply):
  1st layer 8,2 mt./min. [26,9 ft./min.]
  5th layer 15,2 mt./min. [49,9 ft./min.]

Features

• Single stage hardened steel planetary gears in oil bath
• Hydraulic multi disc negative brake system
• Over-centre valve
• Manual Clutch for drum Freespooling
• Hydraulic orbital motor
• Drum length (distance between drum flanges):
  EPH 6000 FN standard drum 252 mm [9,9 in]
• Drum barrel dia.102 mm [4,0 in]
• Wire rope recommended dia.13 mm [1/2”]

Compliance

CE Machinery Directive  98/37/EEC

Accessories

• Galvanized Heavy-duty roller fairlead (rollers in steel)
• Galvanized level winder
• Air clutch for drum Freespooling

---
