Applications

Screw-to-connect coupling, safety sleeve

Screw-on male couplings suitable for general purpose applications. Connectable under residual pressure. High resistance to pressure and flow impulses. Equipped with an additional safety sleeve to prevent accidental disconnections proveked by vibrations. Interchangeable according to ISO 14541 standard.


Items

.

Size (mm)  PartNumber Thread HEX1 HEX3 D1 D2 L1
 12,5 CVLS080/58SAEMV 7/8"-14 UNF FEMALE ORB 30 38 49   73
 25 CVLS16 34GAS MV BSPP 3/4" FEMALE 41 55 69 50 96
 25 CVLS1611/114S M 1-11/16"-12 UN MALE ORFS 45 55 69 50 96
 25 CVLS1611/1SAE M 1-7/16"-12 UN MALE ORFS 45 55 69 50 96

Download Cvls Catalogue
